Drawing Image for Dynamic Flex

Dynamic Flex Solo 60 Pixel IP20

Dynamic Flex is an advanced range of colour-changing and pixel-controllable LED light engines, developed for theatrical, entertainment, and interactive projects requiring addressable control and reliable performance. The range is structured across three distinct categories to suit different levels of control. Dynamic Flex offers standard colour-changing options, available in RGB, RGBW, and RGBWW. Dynamic Flex Pixel features group-addressable LEDs, available in 12 px and 24 px per metre configurations, in Single Colour, RGB, and RGBW. For maximum control, Dynamic Flex Solo Pixel provides individually addressable LEDs, with options from 30 px to 120 px per metre, also available in Single Colour, RGB, and RGBW. A wide selection of chip counts, IP ratings, and output options is available across all categories, enabling flexible specification across a broad range of dynamic lighting applications.

Power Consumption

12 | 13.5 W/m

Cutting Intervals

16.66 mm

Voltage

5 V DC

Beam Angle

120 °

LED Pitch

16.66 mm

Max Power Length

3000 mm

Pixels

60 PX/m

Product Options

Show Filters
Filter

Compatible Accessories

Flex Profiles
Flex Profile Recessed 2315
  • Flex Profile Recessed 2315

  • View Drawing
    Flex Profile Recessed 2315

    Flex Profile Recessed 2315

    Dimensions 23.2 mm x 15.3 mm
    Max Flex Width 10 mm
    Colour Grey
    Pitch For Diffusion 80 LED/m
    View product
    Flex Profile Surface 1715
  • Flex Profile Surface 1715

  • View Drawing
    Flex Profile Surface 1715

    Flex Profile Surface 1715

    Dimensions 17.1 mm x 15.4 mm
    Max Flex Width 12 mm
    Colour Grey
    Pitch For Diffusion 80 LED/m
    View product
    Flex Profile Surface Corner 1616
  • Flex Profile Surface Corner 1616

  • View Drawing
    Flex Profile Surface Corner 1616

    Flex Profile Surface Corner 1616

    Dimensions 16 mm x 16 mm
    Max Flex Width 10 mm
    Colour Grey
    Pitch For Diffusion 80 LED/m
    View product
    Flex Profile Surface Corner 1617
  • Flex Profile Surface Corner 1617

  • View Drawing
    Flex Profile Surface Corner 1617

    Flex Profile Surface Corner 1617

    Dimensions 16 mm x 16 mm
    Max Flex Width 10 mm
    Colour Grey
    Pitch For Diffusion 160 LED/m
    View product
    Flex Profile Surface 2020
  • Flex Profile Surface 2020

  • View Drawing
    Flex Profile Surface 2020

    Flex Profile Surface 2020

    Dimensions 19.6 mm x 19.92 mm
    Max Flex Width 14 mm
    Colour Grey
    Pitch For Diffusion 80 LED/m
    View product
    Flex Profile Surface 2021
  • Flex Profile Surface 2021

  • View Drawing
    Flex Profile Surface 2021

    Flex Profile Surface 2021

    Dimensions 19.7 mm x 20 mm
    Max Flex Width 14 mm
    Colour Grey
    Pitch For Diffusion 80 LED/m
    View product
