Lumen Line

The Lumen Line features high-CRI LED light engines. With CRI of 98+ and R9 values of 99+, the range offers exceptional colour precision, ideal for high-end retail and hospitality applications. With IP20, IP54, and IP67 options, Lumen Line is suitable for both indoor and outdoor environments. The range offers design flexibility with various chip counts, wattages, and colour options including Single-Colour and Dynamic White, as well as the unique Solo variant with individual LED cutting intervals.

Colour Temperature
Lumens
180
lm/m
2879
lm/m

Wattage
LED Per Metre
80
LED/m
240
LED/m

Cutting Intervals
IP Rating
Show Filters

Filters

Colour Temperature
Lumens
180
lm/m
2879
lm/m

LED Per Metre
80
LED/m
240
LED/m

Wattage
IP Rating
  • Lumen Line 80 IP20

  • View Drawing

    Lumen Line 80 IP20

    Power Consumption 2.4 | 4.8 | 9.6 W/m
    Cutting Intervals 100 mm
    Voltage 24 V DC
    Beam Angle 120 °
    LED Pitch 12.5 mm
    Max Power Length 8000 mm
    View product
    Power Consumption 2.4 | 4.8 | 9.6 W/m
    Cutting Intervals 100 mm
    Voltage 24 V DC
    Beam Angle 120 °
    LED Pitch 12.5 mm
    Max Power Length 8000 mm
  • Lumen Line 80 IP54

  • View Drawing

    Lumen Line 80 IP54

    Power Consumption 2.4 | 4.8 | 9.6 W/m
    Cutting Intervals 100 mm
    Voltage 24 V DC
    Beam Angle 120 °
    LED Pitch 12.5 mm
    Max Power Length 8000 mm
    View product
    Power Consumption 2.4 | 4.8 | 9.6 W/m
    Cutting Intervals 100 mm
    Voltage 24 V DC
    Beam Angle 120 °
    LED Pitch 12.5 mm
    Max Power Length 8000 mm
  • Lumen Line 80 IP67

  • View Drawing

    Lumen Line 80 IP67

    Power Consumption 2.4 | 4.8 | 9.6 W/m
    Cutting Intervals 100 mm
    Voltage 24 V DC
    Beam Angle 120 °
    LED Pitch 12.5 mm
    Max Power Length 8000 mm
    View product
    Power Consumption 2.4 | 4.8 | 9.6 W/m
    Cutting Intervals 100 mm
    Voltage 24 V DC
    Beam Angle 120 °
    LED Pitch 12.5 mm
    Max Power Length 8000 mm
  • Lumen Line 160 IP20

  • View Drawing

    Lumen Line 160 IP20

    Power Consumption 2.4 > 19.2 W/m
    Cutting Intervals 50 mm
    Voltage 24 V DC
    Beam Angle 120 °
    LED Pitch 6.25 mm
    Max Power Length 10000 mm
    View product
    Power Consumption 2.4 > 19.2 W/m
    Cutting Intervals 50 mm
    Voltage 24 V DC
    Beam Angle 120 °
    LED Pitch 6.25 mm
    Max Power Length 10000 mm
  • Lumen Line 160 IP54

  • View Drawing

    Lumen Line 160 IP54

    Power Consumption 2.4 > 19.2 W/m
    Cutting Intervals 50 mm
    Voltage 24 V DC
    Beam Angle 120 °
    LED Pitch 6.25 mm
    Max Power Length 10000 mm
    View product
    Power Consumption 2.4 > 19.2 W/m
    Cutting Intervals 50 mm
    Voltage 24 V DC
    Beam Angle 120 °
    LED Pitch 6.25 mm
    Max Power Length 10000 mm
  • Lumen Line 160 IP67

  • View Drawing

    Lumen Line 160 IP67

    Power Consumption 2.4 | 4.8 | 9.6 | 14.4 W/m
    Cutting Intervals 50 mm
    Voltage 24 V DC
    Beam Angle 120 °
    LED Pitch 6.25 mm
    Max Power Length 10000 mm
    View product
    Power Consumption 2.4 | 4.8 | 9.6 | 14.4 W/m
    Cutting Intervals 50 mm
    Voltage 24 V DC
    Beam Angle 120 °
    LED Pitch 6.25 mm
    Max Power Length 10000 mm
  • Lumen Line 240 IP20

  • View Drawing

    Lumen Line 240 IP20

    Power Consumption 2.4 > 24 W/m
    Cutting Intervals 33.33 mm
    Voltage 24 V DC
    Beam Angle 120 °
    LED Pitch 4.16 mm
    Max Power Length 12000 mm
    View product
    Power Consumption 2.4 > 24 W/m
    Cutting Intervals 33.33 mm
    Voltage 24 V DC
    Beam Angle 120 °
    LED Pitch 4.16 mm
    Max Power Length 12000 mm
  • Lumen Line 240 IP54

  • View Drawing

    Lumen Line 240 IP54

    Power Consumption 2.4 > 24 W/m
    Cutting Intervals 33.33 mm
    Voltage 24 V DC
    Beam Angle 120 °
    LED Pitch 4.16 mm
    Max Power Length 12000 mm
    View product
    Power Consumption 2.4 > 24 W/m
    Cutting Intervals 33.33 mm
    Voltage 24 V DC
    Beam Angle 120 °
    LED Pitch 4.16 mm
    Max Power Length 12000 mm
  • Lumen Line 240 IP67

  • View Drawing

    Lumen Line 240 IP67

    Power Consumption 2.4 > 19.2 W/m
    Cutting Intervals 33.33 mm
    Voltage 24 V DC
    Beam Angle 120 °
    LED Pitch 4.16 mm
    Max Power Length 12000 mm
    View product
    Power Consumption 2.4 > 19.2 W/m
    Cutting Intervals 33.33 mm
    Voltage 24 V DC
    Beam Angle 120 °
    LED Pitch 4.16 mm
    Max Power Length 12000 mm
  • Lumen Line Solo 160 IP20

  • View Drawing

    Lumen Line Solo 160 IP20

    Power Consumption 2.4 | 4.8 | 9.6 W/m
    Cutting Intervals 6.25 mm
    Voltage 24 V DC
    Beam Angle 120 °
    LED Pitch 6.25 mm
    Max Power Length 14000 mm
    View product
    Power Consumption 2.4 | 4.8 | 9.6 W/m
    Cutting Intervals 6.25 mm
    Voltage 24 V DC
    Beam Angle 120 °
    LED Pitch 6.25 mm
    Max Power Length 14000 mm
  • Lumen Line Solo 160 IP54

  • View Drawing

    Lumen Line Solo 160 IP54

    Power Consumption 2.4 | 4.8 | 9.6 W/m
    Cutting Intervals 6.25 mm
    Voltage 24 V DC
    Beam Angle 120 °
    LED Pitch 6.25 mm
    Max Power Length 14000 mm
    View product
    Power Consumption 2.4 | 4.8 | 9.6 W/m
    Cutting Intervals 6.25 mm
    Voltage 24 V DC
    Beam Angle 120 °
    LED Pitch 6.25 mm
    Max Power Length 14000 mm
  • Lumen Line Solo 160 IP67

  • View Drawing

    Lumen Line Solo 160 IP67

    Power Consumption 2.4 | 4.8 | 9.6 W/m
    Cutting Intervals 6.25 mm
    Voltage 24 V DC
    Beam Angle 120 °
    LED Pitch 6.25 mm
    Max Power Length 14000 mm
    View product
    Power Consumption 2.4 | 4.8 | 9.6 W/m
    Cutting Intervals 6.25 mm
    Voltage 24 V DC
    Beam Angle 120 °
    LED Pitch 6.25 mm
    Max Power Length 14000 mm
  • Lumen Line Dynamic White 240 IP20

  • View Drawing

    Lumen Line Dynamic White 240 IP20

    Power Consumption 4.8 > 24 W/m
    Cutting Intervals 50 mm
    Voltage 24 V DC
    Beam Angle 120 °
    LED Pitch 4.17 mm
    Max Power Length 15000 mm
    View product
    Power Consumption 4.8 > 24 W/m
    Cutting Intervals 50 mm
    Voltage 24 V DC
    Beam Angle 120 °
    LED Pitch 4.17 mm
    Max Power Length 15000 mm
  • Lumen Line Dynamic White 240 IP54

  • View Drawing

    Lumen Line Dynamic White 240 IP54

    Power Consumption 4.8 > 24 W/m
    Cutting Intervals 50 mm
    Voltage 24 V DC
    Beam Angle 120 °
    LED Pitch 4.17 mm
    Max Power Length 15000 mm
    View product
    Power Consumption 4.8 > 24 W/m
    Cutting Intervals 50 mm
    Voltage 24 V DC
    Beam Angle 120 °
    LED Pitch 4.17 mm
    Max Power Length 15000 mm
  • Lumen Line Dynamic White 240 IP67

  • View Drawing

    Lumen Line Dynamic White 240 IP67

    Power Consumption 4.8 | 9.6 | 14.4 | 19.2 W/m
    Cutting Intervals 50 mm
    Voltage 24 V DC
    Beam Angle 120 °
    LED Pitch 4.17 mm
    Max Power Length 15000 mm
    View product
    Power Consumption 4.8 | 9.6 | 14.4 | 19.2 W/m
    Cutting Intervals 50 mm
    Voltage 24 V DC
    Beam Angle 120 °
    LED Pitch 4.17 mm
    Max Power Length 15000 mm
