Drawing Image for Triple Line Dynamic White 80 IP54

Triple Line Dynamic White 80 IP54

The Multi Line family consists of LED light engines featuring multiple parallel lines of LEDs, engineered specifically to complement wider profiles. Available in IP20 and IP54, with colour options including Single Colour, Dynamic White, RGB, RGBW, and Pixel, Multi Line is designed to deliver uniform luminance across the full emitting surface. The range also streamlines installation by reducing the need for intricate cabling and soldering, helping to significantly shorten setup time on site. Available in Double, Triple, and Quadruple Line configurations, with a broad selection of chip counts and wattages, Multi Line supports flexible specification across diverse applications.

Power Consumption

14.4 > 28.8 W/m

Cutting Intervals

12.5 mm

Voltage

24 V DC

Beam Angle

120 °

LED Pitch

6.25 mm

Max Power Length

6000 mm
