Drawing Image for Double Line RGBW 120 IP20

Double Line RGBW 120 IP20

The Multi Line family consists of LED light engines featuring multiple parallel lines of LEDs, engineered specifically to complement wider profiles. Available in IP20 and IP54, with colour options including Single Colour, Dynamic White, RGB, RGBW, and Pixel, Multi Line is designed to deliver uniform luminance across the full emitting surface. The range also streamlines installation by reducing the need for intricate cabling and soldering, helping to significantly shorten setup time on site. Available in Double, Triple, and Quadruple Line configurations, with a broad selection of chip counts and wattages, Multi Line supports flexible specification across diverse applications.

Power Consumption

25 W/m

Cutting Intervals

50 mm

Voltage

24 V DC

Beam Angle

120 °

LED Pitch

8.33 mm

Max Power Length

5000 mm

Product Options

Show Filters
Filter

Compatible Accessories

Flex Profiles
Flex Profile Surface 2516
  • Flex Profile Surface 2516

  • View Drawing
    Flex Profile Surface 2516

    Flex Profile Surface 2516

    Dimensions 25.4 mm x 16 mm
    Max Flex Width 18 mm
    Colour Grey
    Pitch For Diffusion 160 LED/m
    View product
    Flex Profile Recessed 4650
  • Flex Profile Recessed 4650

  • View Drawing
    Flex Profile Recessed 4650

    Flex Profile Recessed 4650

    Dimensions 45.7 mm x 50.1 mm
    Max Flex Width 18 mm
    Colour Grey
    Pitch For Diffusion 160 LED/m
    View product
    Flex Profile Recessed 3111
  • Flex Profile Recessed 3111

  • View Drawing
    Flex Profile Recessed 3111

    Flex Profile Recessed 3111

    Dimensions 30.59 mm x 10.9 mm
    Max Flex Width 18 mm
    Colour Grey
    Pitch For Diffusion 160 LED/m
    View product
    Flex Profile Surface Corner 3031
  • Flex Profile Surface Corner 3031

  • View Drawing
    Flex Profile Surface Corner 3031

    Flex Profile Surface Corner 3031

    Dimensions 30 mm x 30 mm
    Max Flex Width 18 mm
    Colour Grey
    Pitch For Diffusion 80 LED/m
    View product
    Flex Profile Surface 2415
  • Flex Profile Surface 2415

  • View Drawing
    Flex Profile Surface 2415

    Flex Profile Surface 2415

    Dimensions 23.5 mm x 15 mm
    Max Flex Width 18 mm
    Colour Grey
    Pitch For Diffusion 80 LED/m
    View product
    Flex Profile Surface 2633
  • Flex Profile Surface 2633

  • View Drawing
    Flex Profile Surface 2633

    Flex Profile Surface 2633

    Dimensions 26.2 mm x 32.87 mm
    Max Flex Width 18 mm
    Colour Grey
    Pitch For Diffusion 160 LED/m
    View product
    Flex Profile Surface D60
  • Flex Profile Surface D60

  • View Drawing
    Flex Profile Surface D60

    Flex Profile Surface D60

    Dimensions 63.6 mm x 16 mm
    Max Flex Width 14 mm
    Colour Grey
    Pitch For Diffusion 80 LED/m
    View product
