Drawing Image for Triple Line 120 IP54

Triple Line 120 IP54

The Multi Line family consists of LED light engines featuring multiple parallel lines of LEDs, engineered specifically to complement wider profiles. Available in IP20 and IP54, with colour options including Single Colour, Dynamic White, RGB, RGBW, and Pixel, Multi Line is designed to deliver uniform luminance across the full emitting surface. The range also streamlines installation by reducing the need for intricate cabling and soldering, helping to significantly shorten setup time on site. Available in Double, Triple, and Quadruple Line configurations, with a broad selection of chip counts and wattages, Multi Line supports flexible specification across diverse applications.

Power Consumption

14.4 > 28.8 W/m

Cutting Intervals

50 mm

Voltage

24 V DC

Beam Angle

120 °

LED Pitch

8.33 mm

Max Power Length

7000 mm

Product Options

Show Filters
Filter

Compatible Accessories

Flex Profiles
Flex Profile Recessed 6535
  • Flex Profile Recessed 6535

  • View Drawing
    Flex Profile Recessed 6535

    Flex Profile Recessed 6535

    Dimensions 65 mm x 35 mm
    Max Flex Width 36 mm
    Colour Grey
    Pitch For Diffusion 80 LED/m
    View product
    Flex Profile Surface 5035
  • Flex Profile Surface 5035

  • View Drawing
    Flex Profile Surface 5035

    Flex Profile Surface 5035

    Dimensions 50 mm x 35 mm
    Max Flex Width 39.86 mm
    Colour Grey
    Pitch For Diffusion 80 LED/m
    View product
    Flex Profile Surface Round 4542
  • Flex Profile Surface Round 4542

  • View Drawing
    Flex Profile Surface Round 4542

    Flex Profile Surface Round 4542

    Dimensions 45 mm x 41.88 mm
    Max Flex Width 36 mm
    Colour Grey
    Pitch For Diffusion 80 LED/m
    View product
    Flex Profile Surface 7540
  • Flex Profile Surface 7540

  • View Drawing
    Flex Profile Surface 7540

    Flex Profile Surface 7540

    Dimensions 75 mm x 40 mm
    Max Flex Width 36 mm
    Colour Grey
    Pitch For Diffusion 80 LED/m
    View product
