Drawing Image for Nano Flex Solo 160 IP20

Nano Flex Solo 160 IP20

Nano Flex is our ultra-slim LED light engine range, built around 4 millimetre-wide PCBs for discreet integration in interior applications. Designed for cabinetry, joinery, and furniture detailing, it delivers high-performance output from a minimal visual footprint. Available in Single Colour, Dim To Warm and Dynamic White, Nano Flex offers a wide selection of chip counts and wattages, alongside specialist variants including Solo Chip Edge and Nano Line, delivering exceptional flexibility across a wide variety of lighting configurations.

Power Consumption

2.4 | 4.8 | 9.6 W/m

Cutting Intervals

6.25 mm

Voltage

24 V DC

Beam Angle

120 °

LED Pitch

6.25 mm

Max Power Length

6000 mm

Product Options

Show Filters
Filter

Compatible Accessories

Flex Profiles
Flex Profile Nano 0812
  • Flex Profile Nano 0812

  • View Drawing
    Flex Profile Nano 0812

    Flex Profile Nano 0812

    Dimensions 7.8 mm x 12 mm
    Max Flex Width 5 mm
    Colour Grey
    Pitch For Diffusion 160 LED/m
    View product
    Flex Profile Nano 1312
  • Flex Profile Nano 1312

  • View Drawing
    Flex Profile Nano 1312

    Flex Profile Nano 1312

    Dimensions 12.8 mm x 12 mm
    Max Flex Width 5 mm
    Colour Grey
    Pitch For Diffusion 160 LED/m
    View product
    Flex Profile Nano 1213
  • Flex Profile Nano 1213

  • View Drawing
    Flex Profile Nano 1213

    Flex Profile Nano 1213

    Dimensions 12 mm x 13 mm
    Max Flex Width 5 mm
    Colour Grey
    Pitch For Diffusion 240 LED/m
    View product
    Flex Profile Nano 1013
  • Flex Profile Nano 1013

  • View Drawing
    Flex Profile Nano 1013

    Flex Profile Nano 1013

    Dimensions 10 mm x 13.1 mm
    Max Flex Width 8 mm
    Colour Grey
    Pitch For Diffusion 160 LED/m
    View product
    Flex Profile Nano 0809
  • Flex Profile Nano 0809

  • View Drawing
    Flex Profile Nano 0809

    Flex Profile Nano 0809

    Dimensions 7.8 mm x 9 mm
    Max Flex Width 5 mm
    Colour Grey
    Pitch For Diffusion 160 LED/m
    View product
